High Impact 360 Degree Self Rotating Tank Washing Spray Nozzle

FOB Reference Price:Get Latest Price
$1.00 - $18.00 / Pieces | 10 Piece/Pieces (Min. Order)
Model Number:
D41800E
Customization:
Customized logo (Min. Order: 2000 Pieces)
Customized packaging (Min. Order: 2000 Pieces)

More

Graphic customization (Min. Order: 2000 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Farms, Construction works , Energy & Mining
Place of Origin:
Jiangsu, China
Brand Name:
FOG
Condition:
New
Thread Type:
G/ BSPT / NPT or Bolt
Usage:
cleaning the tanks
Usage 2:
Large tanks rinsing and sterilization
Usage 3:
cleaning, sanitizing and foaming applications
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton/box
Port
Shanghai
Product Description
Brand Name
FOG
Place of Origin
Jiangsu, China (Mainland)
Port
Shanghai
Certificates
ISO 9001, ISO14001
Model Number
D41800E
Material
Stainless Steel, Brass, Plastic
Thread type
G/ BSPT / NPT/ Bolt
Inlet Dia.
3/4 to 3
Usage
Cleaning tanks
Application
Tanks rinsing and sterilization

1. Perfect for cleaning, sanitizing and foaming tanks up to 3.7 meters (12 inches)

2. Rotates at nearly constantstant speed of 2 to 30 RPM over a wide range of fluid pressures for entire cleaning

3. Up to four times higher impact than conventional rotating nozzles

4. Flow rate range: 10 to 128 l/min

5. Pressure range: 1.5 to 16 bar

6. Max. operating temperature: 150℃(302℉)

7. Mix. tank opening size: 32 mm (1-1/4" )

8. Spray coverage: 360º

9. Materials: Provide 316L and HASTELLOY® upon request

10.Weight: 0.13 kg

Detailed Images
Related Products


Spray coverage:180° to 360°;
Pressure range: 1 to 12 bar
Tank opening size: 26 mm (1-1/32"), 32 mm (1-1/4" ), 60 mm (2-7/32"), 64 to 102 mm (2.5" to 4" )
Inlet conn.: 1/2" to 3” (G/ BSPT/NPT)

Low pressure operation


Spray coverage: 180º,210º, 240º , 270º,360º

Pressure range: 1 to 10 bar

Tank opening size: 254 mm(10"), 152 mm(10"), 51 mm (2"),  19 to 25 mm (0.75" 1")

Inlet conn.: 3/4" to 3” (G/ BSPT/NPT)


Low pressure operation


Specification: Largest Free Passage, Maximum Free Passage

Spray angle: 30°, 60°, 90°,120°

Pressure: 0.2 bar to 5 bar

Material: SS, PP, CPVC, PVC, Brass

Customized manufacture is available

Quick connect nozzles

0 - 120°  degree spray angle

Clamp ball eyelet nozzles

Pipe clamp Quick connect

Spiral nozzle

Spiral spraying  Full cone

Water mist nozzles

Fine mist, fog spraying

Square nozzles

Square spraying

Tank Mixing Nozzle

Circulate liquids

Our Company

FOG Spraying & Purification Co., Ltd is professional manufacturer of Industrial Nozzles, Spray systems.
Factory direct price, Superior spray performance.
OEM Customized manufacture is available upon request. Best Spray solution to your application.
We guarantee Spray Angle tolerance ≤ 3 % Spray Capacity tolerance ≤3%

Products showcase
                                                                                                        Spray     Nozzle
                 Air Nozzle
              Spiral nozzle
Our Service

OEM Customized manufacture

* Marking and engrave

* Raw mateiral testing

* Spray performance testing

Shipping methods

* Express delivery, Air freight

* Sea freight,

* Land freight

FAQ

Q1:Are you trading company or manufacturer ?

 A: We are professional nozzle manufacturer.

Q2:  How about your delivery time?

A: Generally, it will take 3 to 7 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q3: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can also provide technical support for your applications upon request.
Q4: How to contact us?
A: http://www.fogsp.com/ , Tel: +86 15200892885, Phone & Fax: 86 0512 50314927
QQ: 1782187153; Wechat: 15200892885
